EPL series large pole electro-permanent magnetic chuck
EPL 系列是大极块的电永磁吸盘。
Description:描述
1 No heat build up or deformation provides high precision accuracy.
2 No electricity required to keep the electro-permanent magnetic chuck ON.
3 All metal top plate of brass and steel lamination provides full active magnetic area.
4 Variable transverse pole arrangement, suitable for milling work.
USE:使用：
For heavy milling of large and thick workpieces. For large air gaps.
对于大型和重型工件的粗铣，对于大型空气的间距。
--min. thickness of workpiece:35mm工件的最小厚度：35毫米
--min. size of workpiece:150X150mm2工件最小的尺寸：150X150平方毫米
--nominal holding force:170 N/cm2一般持有力：170牛/平方厘米
Application:应用：
1 For grinding application of all sizes of jobs.
2 Electro-permanent magnetic chucks are suitable for horizontal spindle surface grinding machines as the main cutting thrust is towards the length of the chuck, poles at righ angle of the wheel give more gripping of the job.
Features:特征：
--optimized high energy magnetic system concentration to the workpiece
优化的高能磁系统集中到工件
--total chuck surface active, no “dead” zones
总的吸盘表没有无磁性的区域
--solid mono-block construction
固体单块的建设
--real magnetic(N/S) poles
真正的磁性极块（不是N/S）
--electro-permanent system, guaranteeing safe operation during power failure
电永磁系统，安全运行期间的电力供应是中断的。
--pole separation with brass for optimal wear behaviour
极分离与磨损性能最佳黄铜
--pole plate wearing limit 8mm
极板磨损限制在8mm
--tapped holes grid for fixed or flexible pole raisers on request(M)
固定螺纹孔网格或极点的灵活可根据要求
--T-slots possible on pole pitch P=85mm according DIN650-10H10(T) and on request |
